Fire Retardant Epoxy Resin
Sicomin’s market leading range of heat resistant epoxy and fire retardant epoxy products designed specifically for Construction, Civil Enginering, Aerospace, Rail and Marine applications are designed to deliver high performance laminates whilst also meeting demanding fire regulations.
The fire retardant epoxy resin range is available in a variety of formats suitable for most processing methods including: Laminating, Infusion, Prepregging and Foaming.
heat resistant epoxy, fire retardant epoxy, fire retardant epoxy resin
| | Weight ratio 100 g + .. g | Volume ratio 100 ml + .. m | Pot-life for 500g Mix at 20?C | Mix viscosity at 20?C (CPs) | Working time at 20?C | TG 1 Max ?C | Fire resistance approvals |
|---|
| |
| SR 1126 |
| SR 1126 / SD 1305 | 18 | 23 | > 8 h | 4 200 | > 8 h | 130 | UL94 V0 & FAR25-853 |
| SR 1126 / SD 8202 | 20 | 27 | 3 h 20m (150 g) | 1250 | 5 h 30m | 93 | UL94 V0 & FAR25-853 |
| SR 1126 / SD 8203 | 20 | 26 | 3 h (150 g) | 2 100 | 4 H | 90 | UL94 V0 & FAR25-853 |
| SR 1126 / SD 8205 | 20 | 25 | 51m (150 g) | 2 700 | 2 h 30m | 81 | UL94 V0 & FAR25-853 |
| |
| SR 1500i |
| SR 1500i / SD 2505 | 17 | / | 50 m | - | 3 H | 76 | M1 |
| |
| |
| |
- Low viscosity, fire retardant epoxy resin.
- Designed for infusion, hand laminating and filament winding processes.
- Halogen free and flame retardant.
- Low smoke opacity and toxicity.
More Info
- Meets the stringent fire protection standards specified in construction, automotive and transportation parts.
- Requires post curing in the mould before the part?s release.
- Available with 2 different hardeners
- Offer an exceptional fire resistance with SC FW16 coating (ASTM E84 class A)
| | Weight ratio 100 g + .. g | Volume ratio 100 ml + .. m | Pot-life for 500g Mix at 20?C | Mix viscosity at 20?C (CPs) | Working time at 20?C | TG 1 Max ?C | Fire resistance approvals |
|---|
| |
| SR 1126 |
| SR 1126 / SD 1305 | 18 | 23 | > 8 h | 4 200 | > 8 h | 130 | UL94 V0 & FAR25-853 |
| SR 1126 / SD 8202 | 20 | 27 | 3 h 20m (150 g) | 1250 | 5 h 30m | 93 | UL94 V0 & FAR25-853 |
| SR 1126 / SD 8203 | 20 | 26 | 3 h (150 g) | 2 100 | 4 H | 90 | UL94 V0 & FAR25-853 |
| SR 1126 / SD 8205 | 20 | 25 | 51m (150 g) | 2 700 | 2 h 30m | 81 | UL94 V0 & FAR25-853 |
| |
| SR 1500i |
| SR 1500i / SD 2505 | 17 | / | 50 m | - | 3 H | 76 | M1 |
| |
| |
| |
- The new generation of self-extinguishing products with intumescent properties
- Halogen free
- Laminate classification: UL94 / V0 & FAR25-853 (a)
- Has achieved both Airbus and Boeing?s FST (fire smoke toxicity) standards
| | Weight ratio 100 g + .. g | Volume ratio 100 ml + .. m | Pot-life for 500g Mix at 20?C | Mix viscosity at 20?C (CPs) | Working time at 20?C | TG 1 Max ?C | Fire resistance approvals |
|---|
| |
| SR 1126 |
| SR 1126 / SD 1305 | 18 | 23 | > 8 h | 4 200 | > 8 h | 130 | UL94 V0 & FAR25-853 |
| SR 1126 / SD 8202 | 20 | 27 | 3 h 20m (150 g) | 1250 | 5 h 30m | 93 | UL94 V0 & FAR25-853 |
| SR 1126 / SD 8203 | 20 | 26 | 3 h (150 g) | 2 100 | 4 H | 90 | UL94 V0 & FAR25-853 |
| SR 1126 / SD 8205 | 20 | 25 | 51m (150 g) | 2 700 | 2 h 30m | 81 | UL94 V0 & FAR25-853 |
| |
| SR 1500i |
| SR 1500i / SD 2505 | 17 | / | 50 m | - | 3 H | 76 | M1 |
| |
| |
| |
- Halogen free, Fire retardant epoxy resin
- Meets the stringent fire protection standards specified in DIN EN 45545 HL3, DIN 5510 and FAR 25
- Requires hot post curing in the mould before release of part
- Designed for civil engineering, automotive and transportation components
- Available with 2 range of hardeners, SZ 851x & SD 477x
