Epoxy Foam
A foaming epoxy resin that is one of the only products on the market which has the following characteristics:
- Produces a closed cell epoxy foam from a two part epoxy system
- Available in four standard densities
- Low expansion pressure
- Can be used in-situ
- Finished epoxy foam parts can be used under water
- Can be used in a continuous process
- Foaming epoxy can be coloured
| | Weight ratio 100 g + .. g | Volume ratio 100 ml + .. ml | Free expanded density at 20?C (Kg/m3) | Expansion volume ratio at 20?C | TG 1 Max ?C |
|---|
| |
| PB 170, PB 250, PB 400 & PB 600 / DM 0 |
| PB 170 / DM 02 | 36 | - | 170 | X 6,2 | 90 |
| PB 170 / DM 03 | 31 | - | 170 | X 6,2 | 92 |
| PB 250 / DM 02 | 36 | - | 250 | X 4 | 94 |
| PB 250 / DM 03 | 31 | - | 250 | X 4 | 88 |
| PB 250 / SD 5602 | 90 | 100 | 275 | x 3.7 | 58 |
| |
| |
| PB 270 i, PB 370 i & PB 570 i |
| PB 270 i / DM 02 | 28 | - | 270 | x 3.7 | 85 |
| PB 270 i / DM 03 | 22 | - | 270 | x 3.7 | 81 |
| PB 370 i / DM 02 | 26 | - | 370 | x 2,7 | 88 |
| PB 370 i / DM 03 | 23 | - | 370 | x 2,7 | 88 |
| |
Characteristics
- Closed cell foam production epoxy systems from 170 to 600 kg / m3.
- The PB 170 / DM 0x, PB 250 / DM 0x, PB 400 / DM 0x & PB 600 / DM 0x systems are two part epoxy formulations which produce closed cell low density foams
- The densities obtained are respectively about 170, 250, 400 and 600 kg / m3 (open mould expansion)
- The resulting foam is white but can be coloured with epoxy compatible pigments
- The hardener modifies the curing time and reachable thickness
- The mix evolves in two steps: rapid expansion and a slow hardening of the foam
More Info
Performance Benefits
- Results in a low density foam
- No need for fillers such as microballoons
- Adheres to a wide selection of materials
- Can be poured onto and co-cured with prepregs or other epoxy laminates
- Uniform density
- Excellent resistance to water
- CFC Free
Applications
- Production of epoxy foam
- Core material which can be produced ?in-situ?
- Buoyant and adds density to honeycombs in local areas
- Thermal insulation
- Suitable for making foam blocks to be machined, sculpted or modelled
| | Weight ratio 100 g + .. g | Volume ratio 100 ml + .. ml | Free expanded density at 20?C (Kg/m3) | Expansion volume ratio at 20?C | TG 1 Max ?C |
|---|
| |
| PB 170, PB 250, PB 400 & PB 600 / DM 0 |
| PB 170 / DM 02 | 36 | - | 170 | X 6,2 | 90 |
| PB 170 / DM 03 | 31 | - | 170 | X 6,2 | 92 |
| PB 250 / DM 02 | 36 | - | 250 | X 4 | 94 |
| PB 250 / DM 03 | 31 | - | 250 | X 4 | 88 |
| PB 250 / SD 5602 | 90 | 100 | 275 | x 3.7 | 58 |
| |
| |
| PB 270 i, PB 370 i & PB 570 i |
| PB 270 i / DM 02 | 28 | - | 270 | x 3.7 | 85 |
| PB 270 i / DM 03 | 22 | - | 270 | x 3.7 | 81 |
| PB 370 i / DM 02 | 26 | - | 370 | x 2,7 | 88 |
| PB 370 i / DM 03 | 23 | - | 370 | x 2,7 | 88 |
| |
Characteristics
- Resilient ambient curing epoxy foam
- Two part epoxy formulation which produces closed cell low density foam
- The density obtained is approximately 275 kg / m3 (open mould expansion)
- The resulting foam is white but can be coloured with compatible epoxy pigments
- The hardener modifies the curing time and attainable thickness
- The mix evolves in two step; rapid expansion and a slow hardening of the foam
- Simple 1 to 1 volume ratio
- Produces resilient foams with better flexural elongation without requiring any post curing cycles.
More Info
Performance Benefits
- Results in a low density foam
- No need for fillers such as microballoons
- Can bond to a variety of materials including wet surfaces
- Uniform density
- Excellent resistance to water
- CFC Free
Applications
- Production of epoxy foam
- Core material which can be produced ?in-situ?
- Buoyant and adds density to honeycombs in local areas
- Thermal insulation
- Suitable for making foam blocks to be machined, sculpted or modelled
| | Weight ratio 100 g + .. g | Volume ratio 100 ml + .. ml | Free expanded density at 20?C (Kg/m3) | Expansion volume ratio at 20?C | TG 1 Max ?C |
|---|
| |
| PB 170, PB 250, PB 400 & PB 600 / DM 0 |
| PB 170 / DM 02 | 36 | - | 170 | X 6,2 | 90 |
| PB 170 / DM 03 | 31 | - | 170 | X 6,2 | 92 |
| PB 250 / DM 02 | 36 | - | 250 | X 4 | 94 |
| PB 250 / DM 03 | 31 | - | 250 | X 4 | 88 |
| PB 250 / SD 5602 | 90 | 100 | 275 | x 3.7 | 58 |
| |
| |
| PB 270 i, PB 370 i & PB 570 i |
| PB 270 i / DM 02 | 28 | - | 270 | x 3.7 | 85 |
| PB 270 i / DM 03 | 22 | - | 270 | x 3.7 | 81 |
| PB 370 i / DM 02 | 26 | - | 370 | x 2,7 | 88 |
| PB 370 i / DM 03 | 23 | - | 370 | x 2,7 | 88 |
| |
Characteristics
- Self-extinguishing 2 component epoxy foaming system
- Two part epoxy formulation which produces fireproof closed cell low density foams
- The densities obtained are respectively about 270 and 370 (open mould expansion)
- The resulting foam is white but can be coloured with epoxy compatible pigments
- The hardener modifies the curing time and reachable thickness
- The mix evolves in two steps: rapid expansion and slow hardening of the foam
More Info
Performance Characteristics
- Results in a low density foam
- No need for fillers such as microballoons
- Adheres to a variety of materials
- Can be poured onto and co-cured with prepregs or other epoxy laminates
- Uniform density
- Excellent resistance to water
- CFC Free
Applications
- Production of epoxy foam
- Core material which can be produced ?in-situ?
- Buoyant and adds density to honeycombs in local areas
- Thermal insulation
- Suitable for making foam blocks to be machined, sculpted or modelled
Fire Accreditations
- PB 270 i / DM 03 meets the requirements of the CS 25/FAR 25 ? 25-853 (a) App. F Part.I (a1) (ii) for flammability 12 seconds
- CEAT-Toulouse - France PV # MT-0 8 / 8150155 /P2/A dated 12.12.2008
- Please contact SICOMIN directly for further details of our products Fire Accreditations
