Laminating Resin

Our epoxy laminating resin systems will yield high performance reinforced composite laminates. A large choice of hardeners provides a maximum range of working conditions.

Applications: Marine; Aviation; Automotive; Military; Sport and Leisure; Industry; Transportation; Energy.

SR 8500 / SD 860x epoxy laminating resin

Product Description

Comparative Chart

EPOXY / LAMINATING

Comparative Chart - Epoxy Systems - Laminating

	Weight ratio 100 g + .. g	Volume ratio 100 ml + .. ml	Pot life for 500 g at 20?C	Mix viscosity at 20?C (CPs)	Working time at 20?C	Tg 1 Max (?C)
SR 1500
SR 1500 / SD 2503	33	37	57 m	750	5 H 00	76
SR 1500 / SD 2505	33	37	30 m	800	3 H 15	76
SR 1500 / SD 2507	33	35	13 m	2 200	2 H 00	75
SR 1500 / SD 7561	33	39	8 H 00	530	9 H 00	92
SR 1620
SR 1620 / SD 2625	19	21	30 m	710	3 H 00	97
SR 1620 / SD 2706	19	21	/	/	/	90
SR 1660
SR 1660 / SD 1305	32	39	--	4 000	-	165
SR 1660 / SD 2630	31	36	7 H 45	3 300	/	149
SR 1660 / SD 7820	32	39	6 H	2 400	-	150
SR 1700
SR 1700 / SD 2801	39	48	2 H35	500	12 H	98
SR 1700 / SD 2803	39	45	42 m	700	5 H	101
SR 1700 / SD 2805	39	44	23 m	800	3 H	90
SR 1700 / SD 2806	39	43	14 m	950	1 H 30	90
SR 1700 / SD 7820	36	43	9 H 30	490	9 H 00	140
SR 8200
SR 8200 / SD 8202	31	38	5H20/100g mix	520	8 H 30	100
SR 8200 / SD 8203	31	37	4H40/100g mix	670	6 H 30	106
SR 8200 / SD 8205	31	35	70 mn/100g mix	890	4 H 00	92
SR 8200 / SD 8206	31	34	50 mn/100g mix	1 130	3 H 00	93
SR 8500 / SD 860x
SR 8500 / SD 8601	35	43	15 H 10	750	18 H 00	87
SR 8500 / SD 8605	35	40	39 m	2 800	3 H 00	91

Datasheet

• A multi-purpose epoxy system suited to a wide range of composite applications
• Recommended for the construction of large components
• Excellent mechanical properties

Buy nowor contact us for more information



More Info

• SR 8500 combined with SD 860x system
  Well suited for the production of composite parts working at temperatures of up to 70?C
  A post cure treatment is strongly suggested
• Fast hardener SD 8605 acts as accelerator
• Ultra slow hardener SD 8601 provides low viscosity with high wetting characteristics
  The hardeners can be blended to different ratios to adjust working times
• SR 8500 Black Gel thixotropic formulation also available
• GERMANISCHER LLOYD approved

SR 8200 epoxy laminating resin

Product Description

Comparative Chart

EPOXY / LAMINATING

Comparative Chart - Epoxy Systems - Laminating

	Weight ratio 100 g + .. g	Volume ratio 100 ml + .. ml	Pot life for 500 g at 20?C	Mix viscosity at 20?C (CPs)	Working time at 20?C	Tg 1 Max (?C)
SR 1500
SR 1500 / SD 2503	33	37	57 m	750	5 H 00	76
SR 1500 / SD 2505	33	37	30 m	800	3 H 15	76
SR 1500 / SD 2507	33	35	13 m	2 200	2 H 00	75
SR 1500 / SD 7561	33	39	8 H 00	530	9 H 00	92
SR 1620
SR 1620 / SD 2625	19	21	30 m	710	3 H 00	97
SR 1620 / SD 2706	19	21	/	/	/	90
SR 1660
SR 1660 / SD 1305	32	39	--	4 000	-	165
SR 1660 / SD 2630	31	36	7 H 45	3 300	/	149
SR 1660 / SD 7820	32	39	6 H	2 400	-	150
SR 1700
SR 1700 / SD 2801	39	48	2 H35	500	12 H	98
SR 1700 / SD 2803	39	45	42 m	700	5 H	101
SR 1700 / SD 2805	39	44	23 m	800	3 H	90
SR 1700 / SD 2806	39	43	14 m	950	1 H 30	90
SR 1700 / SD 7820	36	43	9 H 30	490	9 H 00	140
SR 8200
SR 8200 / SD 8202	31	38	5H20/100g mix	520	8 H 30	100
SR 8200 / SD 8203	31	37	4H40/100g mix	670	6 H 30	106
SR 8200 / SD 8205	31	35	70 mn/100g mix	890	4 H 00	92
SR 8200 / SD 8206	31	34	50 mn/100g mix	1 130	3 H 00	93
SR 8500 / SD 860x
SR 8500 / SD 8601	35	43	15 H 10	750	18 H 00	87
SR 8500 / SD 8605	35	40	39 m	2 800	3 H 00	91

Datasheet

• Laminating epoxy containing with no phenol or DDM
• High mechanical performance post cure
• Various hardeners available for use with the SR 8200 resin offering a wide range of reactivity

How to buy
Not available online yet.Contact us to order or find out more



More Info

• SR 8200 combined with Fast hardeners SD 8206 + SD 8205
  Fast curing of the laminates at ambient temperature
  High to very high mechanical properties depending on post cure temperature
• SR 8200 combined with Slow hardener SD 8203 + 8202
  Requires a post cure process
  Recommended for the production of high performance parts and tooling
  Hardeners can be blended to obtain different working characteristics

SR 1700 epoxy laminating resin

Product Description

Comparative Chart

EPOXY / LAMINATING

Comparative Chart - Epoxy Systems - Laminating

	Weight ratio 100 g + .. g	Volume ratio 100 ml + .. ml	Pot life for 500 g at 20?C	Mix viscosity at 20?C (CPs)	Working time at 20?C	Tg 1 Max (?C)
SR 1500
SR 1500 / SD 2503	33	37	57 m	750	5 H 00	76
SR 1500 / SD 2505	33	37	30 m	800	3 H 15	76
SR 1500 / SD 2507	33	35	13 m	2 200	2 H 00	75
SR 1500 / SD 7561	33	39	8 H 00	530	9 H 00	92
SR 1620
SR 1620 / SD 2625	19	21	30 m	710	3 H 00	97
SR 1620 / SD 2706	19	21	/	/	/	90
SR 1660
SR 1660 / SD 1305	32	39	--	4 000	-	165
SR 1660 / SD 2630	31	36	7 H 45	3 300	/	149
SR 1660 / SD 7820	32	39	6 H	2 400	-	150
SR 1700
SR 1700 / SD 2801	39	48	2 H35	500	12 H	98
SR 1700 / SD 2803	39	45	42 m	700	5 H	101
SR 1700 / SD 2805	39	44	23 m	800	3 H	90
SR 1700 / SD 2806	39	43	14 m	950	1 H 30	90
SR 1700 / SD 7820	36	43	9 H 30	490	9 H 00	140
SR 8200
SR 8200 / SD 8202	31	38	5H20/100g mix	520	8 H 30	100
SR 8200 / SD 8203	31	37	4H40/100g mix	670	6 H 30	106
SR 8200 / SD 8205	31	35	70 mn/100g mix	890	4 H 00	92
SR 8200 / SD 8206	31	34	50 mn/100g mix	1 130	3 H 00	93
SR 8500 / SD 860x
SR 8500 / SD 8601	35	43	15 H 10	750	18 H 00	87
SR 8500 / SD 8605	35	40	39 m	2 800	3 H 00	91

Datasheet

• Very high modulus and high mechanical performance epoxy system
• High chemical resistance
• Excellent adhesion to a variety of reinforcements such as glass, aramid and carbon

How to buy
Not available online yet.Contact us to order or find out more



More Info

• Use with Fast hardener SD 2806 and SD 2805:
  Well adapted for vacuum contact moulding of thin or small parts
  Quick repairs
  Fast curing of laminates at ambient temperature
  High mechanical properties at ambient temperature, excellent after post cure
• SR 1700 or slow SD 2803 or ultra slow SD 2801 hardener
  Very low viscosity
  Long working time of up to 8 hours
• SR 1700 / Very slow SD 7820 hardener
  Very low viscosity
  Recommended for the production of 120 ?C tooling for prepregs

SR 1660 epoxy laminating resin

Product Description

Comparative Chart

EPOXY / LAMINATING

Comparative Chart - Epoxy Systems - Laminating

	Weight ratio 100 g + .. g	Volume ratio 100 ml + .. ml	Pot life for 500 g at 20?C	Mix viscosity at 20?C (CPs)	Working time at 20?C	Tg 1 Max (?C)
SR 1500
SR 1500 / SD 2503	33	37	57 m	750	5 H 00	76
SR 1500 / SD 2505	33	37	30 m	800	3 H 15	76
SR 1500 / SD 2507	33	35	13 m	2 200	2 H 00	75
SR 1500 / SD 7561	33	39	8 H 00	530	9 H 00	92
SR 1620
SR 1620 / SD 2625	19	21	30 m	710	3 H 00	97
SR 1620 / SD 2706	19	21	/	/	/	90
SR 1660
SR 1660 / SD 1305	32	39	--	4 000	-	165
SR 1660 / SD 2630	31	36	7 H 45	3 300	/	149
SR 1660 / SD 7820	32	39	6 H	2 400	-	150
SR 1700
SR 1700 / SD 2801	39	48	2 H35	500	12 H	98
SR 1700 / SD 2803	39	45	42 m	700	5 H	101
SR 1700 / SD 2805	39	44	23 m	800	3 H	90
SR 1700 / SD 2806	39	43	14 m	950	1 H 30	90
SR 1700 / SD 7820	36	43	9 H 30	490	9 H 00	140
SR 8200
SR 8200 / SD 8202	31	38	5H20/100g mix	520	8 H 30	100
SR 8200 / SD 8203	31	37	4H40/100g mix	670	6 H 30	106
SR 8200 / SD 8205	31	35	70 mn/100g mix	890	4 H 00	92
SR 8200 / SD 8206	31	34	50 mn/100g mix	1 130	3 H 00	93
SR 8500 / SD 860x
SR 8500 / SD 8601	35	43	15 H 10	750	18 H 00	87
SR 8500 / SD 8605	35	40	39 m	2 800	3 H 00	91

Datasheet

• Laminating and casting epoxy system
• Excellent resistance to chemicals and oxidation
• Low exothermic reaction
• Suitable for laminating, casting and resin transfer moulding techniques

How to buy
Not available online yet.Contact us to order or find out more



More Info

• Typical application: composite tooling for prepregs at 120?C, thermoforming moulds, structural parts working at high temperature
• SR 1660 combined with Hardener SD 2630 or SD 7820:
  Suitable for composites parts operating at up to 140?C
  Hardener with higher reactivity and lower viscosity than SD 2630
  For composites parts operating at up to 140?C.
  Excellent resistance to chemicals and oxidation
  Laminating, casting, resin transfer moulding
  Typical application: composite tooling for prepregs ?120?C?, thermoforming moulds, structural parts working at high temperature
